// Rain Drop Ripples (Converted from GLSL Shadertoy to Direct3D 11 HLSL)
// =========================================================================

cbuffer PS_CONSTANTBUFFER : register(b0)
{
    float FX_Time;
    float FX_SongPosBeats;
    float FX_Width;
    float FX_Height;
    float FX_Beats_on;
    float FX_params_on;
    float FX_param1;
    float FX_param2;
    float FX_param3;
    float FX_param4;
    float FX_param5;
    float FX_VertexCount;
    float FX_BlackAlpha;
    float FX_DrawAlpha;
    float FX_TopologyMode;
    float FX_Zoom;
    float FX_HueShift;
    float FX_PointSize;
    float FX_AudioLevel;
    float FX_BlackReveal;
    float FX_BackgroundR;
    float FX_BackgroundG;
    float FX_BackgroundB;
    float FX_BackgroundOpacity;
};

Texture2D g_Texture : register(t0);
SamplerState g_Sampler : register(s0);

struct PS_INPUT
{
    float4 pos : SV_Position;
};

#define MAX_RADIUS 2
#define DOUBLE_HASH 0

#define HASHSCALE1 0.1031
#define HASHSCALE3 float3(0.1031, 0.1030, 0.0973)

// --- Helper Functions ---
float hash12(float2 p)
{
    float3 p3 = frac(p.xyx * HASHSCALE1);
    p3 += dot(p3, p3.yzx + 19.19);
    return frac((p3.x + p3.y) * p3.z);
}

float2 hash22(float2 p)
{
    float3 p3 = frac(p.xyx * HASHSCALE3);
    p3 += dot(p3, p3.yzx + 19.19);
    return frac((p3.xx + p3.yz) * p3.zy);
}

// --- Main Pixel Shader ---
float4 ps_main(PS_INPUT input) : SV_TARGET
{
    float2 iResolution = float2(FX_Width, FX_Height);

    // Convert D3D11 top-left screen coords to GLSL bottom-left origin
    float2 fragCoord = float2(input.pos.x, iResolution.y - input.pos.y);
    float iTime = FX_Time;

    // Ripple Grid Scale (Param1 modulates resolution if adjusted)
    float resolution = 10.0;
    if (FX_param1 > 0.0)
    {
        resolution = lerp(5.0, 25.0, FX_param1);
    }

    float2 uv = fragCoord.xy / iResolution.y * resolution;
    float2 p0 = floor(uv);
    float2 circles = float2(0.0, 0.0);

    // Calculate Grid Ripples
    for (int j = -MAX_RADIUS; j <= MAX_RADIUS; ++j)
    {
        for (int i = -MAX_RADIUS; i <= MAX_RADIUS; ++i)
        {
            float2 pi = p0 + float2((float) i, (float) j);

#if DOUBLE_HASH
            float2 hsh = hash22(pi);
#else
            float2 hsh = pi;
#endif

            float2 p = pi + hash22(hsh);
            float t = frac(0.3 * iTime + hash12(hsh));
            float2 v = p - uv;

            float d = length(v) - ((float) MAX_RADIUS + 1.0) * t;
            float h = 0.001;

            float d1 = d - h;
            float d2 = d + h;

            float p1 = sin(31.0 * d1) * smoothstep(-0.6, -0.3, d1) * smoothstep(0.0, -0.3, d1);
            float p2 = sin(31.0 * d2) * smoothstep(-0.6, -0.3, d2) * smoothstep(0.0, -0.3, d2);

            // Safe normalize to prevent divide-by-zero artifacts
            float lenV = length(v);
            float2 normV = lenV > 0.0001 ? (v / lenV) : float2(0.0, 0.0);

            circles += 0.5 * normV * ((p2 - p1) / (2.0 * h)) * (1.0 - t) * (1.0 - t);
        }
    }

    circles /= (float) ((MAX_RADIUS * 2 + 1) * (MAX_RADIUS * 2 + 1));

    // Calculate Ripple Distortion Intensity
    float intensity = lerp(
        0.01,
        0.15,
        smoothstep(0.1, 0.6, abs(frac(0.05 * iTime + 0.5) * 2.0 - 1.0))
    );

    // Optional audio reactivity boost when music plays
    intensity *= (1.0 + FX_AudioLevel * 1.5 * FX_param2);

    // Compute Texture UV Displacement
    float2 texUV = fragCoord.xy / iResolution.xy;
    texUV.y = 1.0 - texUV.y;

    texUV.x += intensity * circles.x;
    texUV.y -= intensity * circles.y;

    // Clamp UVs to avoid edge wrap artifacts
    texUV = clamp(texUV, float2(0.001, 0.001), float2(0.999, 0.999));

    // Sample video texture
    float3 color = g_Texture.Sample(g_Sampler, texUV).rgb;

    return float4(color, FX_DrawAlpha);
}
